Cooling of granules is an indispensible process of pelletizing section. Temperature of granules from pellet mill can be reduced from 70℃——90℃ to 3℃ to 5℃ higher than the room temperature by using the reverse-flow cooler, and to the required water moisture(≤12.50℃) for the convenience of pellet transport and preservation.
Photoes of pellets cooler machine:
Technology parameter of pellet cooler machine:
| Model | Cooling Volume (m3) |
Output t/h |
Cooling Time min | Air-absorbed Volume (m3/h) |
Power （KW） |
| SKLN11 | 1 | 0.5~1 | 6-10 | 5000 | 2.2 |
| SKLN14 | 2.5 | 1~2 | 6-10 | 10000 | 3 |
| SKLN19 | 5 | 3~6 | 6-10 | 15000 | 3 |
| SKLN22 | 8 | 7-9 | 6-10 | 27000 | 2.2+1.5 |
| SKLN28 | 10.8 | 11~14 | 10~20 | 54000 | 5.5+1.1 |
Introduction of Wood Pellet Cooler :
- Autocontrol cooling period. It makes the fresh pellets hard dry.
- Cool air flows from bottom to top, while the pellet drop from top to bottom, they fully meet and cool completely. The manufacturing steel plates is 3mm thick. The cooling system consists of Vessel, Wind-in Cone, Discharge System, Feed Port, Exhaust Inlet, Level Control Indicator.This equipment should be used with Air Lock Feeder, Cooling Wind Net.
- The Vessel is made of good quality carbon steel. It has Feed Port, Exhaust Inlet, Level Sensor Window, Stable Plates,etc. The Wind-in Cone is made by welding the punched screen deck groups. It has discharge port, wind inlet, connection flange,etc.
- Discharge System consists of shell, discharge impeller, driving system,etc. The Level Control Indicator consists of sensor level indicator, level adjustment system,etc.
- The cooler can be equipped with Star-valve discharging System;continously and stable discharge.
