Equipment Delivery for Garden Waste Crushing Project

By:Miss Season Tian
Position:Operation Director
Oct 25, 2023
SIMEC has completed the fabrication of double shaft shredder SD1000, double motor hammer crusher DMC1500, movable belt conveyor, bag filter, control cabinet and other spare parts for our Cyprus client. He ordered the equipment for the aim of processing the garden wastes (palm leaf, trunk and so on) into small pieces and make biomass pellets in the subsequent processing stages.

All the equipment is ready for delivery from Qingdao port, shipped by 1 set of 40 feet GP container.

Detail Packing List:
No. Name Size (mm) Gross Weight（kg）
1 Bottome of hammer crusher+Screw conveyor ( Pipes inside) 3850*2150*2000mm 70
2 Head of hammer crusher 2350*1150*1950mm 2000
3 8m belt conveyor 8100*1400*670mm 500
4 Support of 8m belt conveyor 1200*500*350mm 20
5 Hopper piece of 8m belt conveyor 1350*1170*350 30
6 Platform part of hammer crusher 3350*520*100 30
7 Wooden case 1100*670*1050 1000
8 Wooden case 1100*670*1050 1000
9 Bottom of bag filter 1300*1290*2400 150
10 Heat of bag filter 1300*1290*1900 300
11 Shredder 5100*1450*2230 5000
12 Discharging belt conveyor of 8m shredder 2100*850*310 300
13 Securety bar I   20
14 Securety bar II 20
15 Securety bar III 20
16 Extra hopper of shredder 2400*2000*1600 40
17 Wheels of 8m belt conveyor 2300*1650*570 40
18 ladder of hammer crusher 1800*560*150 10
19 Belt cover 1700*340*200 5
20 Belt cover 1700*340*200 5
21 Control cabinet 2000*1200*800 400
    Sub-Total 10960

Photos of Packaged Equipment:
Garden Waste Shredder

Belt Conveyor

Equipment in Plywood Box

Shredder Being Packaged


Upper Part of Shredder

Upper Parts of Garden Waste Crusher

Lower Part of Bag Filter

Electric Control Cabinet of Shredder

Machine Frame

Spare Parts of Garden Waste Crusher


Release date: 2017-07-28
