Control Cabinet For SPM520 Pellet Mill in Vietnam

By:Miss Season Tian
Position:Operation Director
Oct 11, 2023
The control cabinet is ready for delivery to HoChiMinh Port, Vietnam. Its control range includes material feeder, SPM520 pellet mill, bucket elevator, pellet cooler, sifter, etc.
Control Cabinet
Control Cabinet
Frequency Converter
Frequency Converter

Main Specification of Control Panel:
  • Simulation control screen to show the running status of all machines.
  • Frequency converter brand is Mitsubishi.
  • All circuit breakers and starters will be “CHINT” brand.
  • Star Delta Starting for the 75Kw motors of pellet mill.
  • Automatic overload protection and security system. Ampere meter, volt meter, RPM meter and adjust device included.
  • System operation chain protection and alarm system included.
  • Roller Bearing Temperature Monitoring & Alarm System.
Inner View of The Control Cabinet
Inner View of Control Cabinet
Inner View of The Electric Control Cabinet.
Inner View of Controller


Delivery Details of the Control Cabinet:
Packing size: 1180x800x1980
Gross weight: 360kg
Net weight：240kg

Control Cabinet Packing
Control Cabinet Packaged to be delivered
Electric Control Cabinet Packing
Electric control cabinet Packaged to be delivered

Release date: 2016-12-27
