Biomass Pellets Test Equipment Delivery to Vietnam
SIMEC can provide the devices to test the Moisture, Calorific Value, Ash Content and Volatiles. The devices can be operated on site simply. The tester can get the accurate results in a short time.
One of our customers from Vietnam has just ordered the pellet moisture tester and ash content tester for his 10 TPH wood pellet production line.
Pellet Moisture Test Equipment
Pellet Moisture Tester
Pellet Ash Content & Volatilize Tester
Pellet Ash Content & Volatilize Equipment
Product Introduction:
Wood Pellet Moisture Tester
Wood Pellet Ash Tester
Temperature Control Device
Wood Pellet Moisture Tester
Working Principle:
To dry the wood pellets in the rated time and temperature. To compare the weight of the dried wood pellet sample with the undried sample.
Features:
- Adopt the digital temperature adjusting system, sensitive, accurate and convenient;
- Exclusive design for wood pellets, preventing the splash during the drying;
- Fresh air inlet in the bottom of the device and drain tap set on the top. Fresh air goes into the bottom and out from the top. The thermal field is more even;
- The device is made of steel plate and with observation window, which is easy to observe the working condition inside the chamber.
- Power: 2 Kw
Wood Pellet Ash Tester
- This high temperature furnace is made of light fireproofing material, high strength, good thermal insulation and fast temperature elevation.
- Inner size（mm）：325×200×125
- Highest Furnace Temperature：1200℃
- Power：4KW
- This device is used to control the temperature of the furnace. Different standard require different temperature and quantity of sample.
- PID method to adjust the temperature.
- Applied temperature range: Indoor temperature-1200℃ applied with K thermal couple.
- Power：AC220V±15% 50Hz
- Working Time: Continuous
Release date: 2016-06-08
