SIMEC ROTARY DRYER FOR DRYING SOFT HORSE BEDDING CHIPS

By:Mr Darren Chen
Position:Project Sales Director
Jan 04, 2021
Soft white wood, such as albasia wood, pine wood, fir wood etc. are good raw materials for making horse bedding. One of our Indonesian customers has the albasia wood waste from the sawmills such as wood slabs, wood chips, etc. He will recycle the waste to produce high quality horse bedding products.
albasia-wood-waste
Albasia Wood Waste

soft-horse-bedding-chips
Soft Horse Bedding Chips



The inherent properties of soft bedding chips including:
  • Soft chip bedding that stays put;
  • Comfortable and warm for the horses in winter, yet cool in summer;
  • Dust extracted - helping to maintain a healthy respiratory system for horse and human;
  • Sterilized without the use of any chemicals - for a cleaner, healthier horse;
  • Odor elimination properties - reducing the smell of ammonia in the air;
  • Does not attract vermin as with other bedding material such as straw;
  • "Stay-dry" top layer - the soft chip bedding stack allows liquids to run through and be absorbed at the bottom of the stack, whilst allowing the top parts to dry off and remain warm for the horse.
Processing technology of the soft chip bedding is not complex, chipping the soft wood into small chips firstly, then dry the soft chips. The size of the chips can be customized. The moisture of the soft chip, which would affect the quality of the products directly, is the most important point.

The soft chip dryer we delivered to our customer is a single layer rotary drum dryer, as a pilot project. It has a diameter of 2 meters, and length of 11 meters. The drum can be loaded in a 40’ GP container.
horse-bedding-chips-rotary-dryer
Horse Bedding Chips Rotary Dryer

It is one of our rotary dryers especially for drying wood chips. The design of steel shoveling plates can shovel the chips up and down while the drum is rotating, which make sure that the wood chips are dried evenly inside the drum. The spark-killing system and the anti-explosion design guarantee the safe operation.

Operation Video of Wood Chip Rotary Dryer
  • Improved design which increased the drying distance and efficiency;
  • Negative pressure system to prevent any dust-release;
  • Rotation speed adjustable, frequency control driven motors;
  • Temperature of the inside dyer can be shown on the control panel;
shovelling-plates-inside-the-dryer
Shovelling Plates Inside The Dryer

raw-material-inlet-and-hot-air-inlet
Raw Material Inlet & Hot Air Inlet

electric-control-cabinet
Electric Control Cabinet



Actually, the price of the soft chip bedding is much higher than the fuel chips. To produce soft chip bedding will bring more benefits to the producers. SIMEC supply technique and equipment support for soft chip bedding manufacturers. We Engineer Your Success!
