Corncob Pellet Plant Delivery to Thailand

By:Miss Season Tian
Position:Operation Director
Oct 20, 2023
SIMEC is going to deliver a set of pelleting equipment for Thailand Energy Administration for their agricultural residue comprehensive recycle utilization. SIMEC supplies reliable equipments and professional services. After weighing a lot of manufacturers, they chose SIMEC as their supplier.

All the raw materials are collected from plantation and farms, after crushing, pelleting and cooling, the pellets can be used as clean fuel in the local rural area.

This project is equipped with MFSP80-I hammer crusher, SPM520 pellet machine, pellet cooler and sifter, the entire production line is controlled by simulation electric cabinet. All of these equipment is supplied by SIMEC.

Now the devices to be delivered are inspected and packaged already, will be shipped by two 40GP containers from Qingdao Port to Bangkok Port soon.
SPM520 Pellet Mill

Cabinet Controller

Air Pipes

Conveyor

Pipes

Sifter of Cooler

Supporters

Spare Parts

Packaged Cyclone

Packaged SPM520 Pellet Mill

SIMEC Engineers and Thailand Customers

Packaged Equipment to be Delivery


SPECIFIC PACKING LIST OF CORN COB PELLET LINE (SIMEC160912C)
No. Item Size (mm) Weight (T) Remarks
1 36/28 Bucket Elevator Head and Base (2 units) 1410x1110x1750 0.636 2 heads and 2 bases of the buckt elevators;
2 sets of reducer;
2 sets of motor frame.
2 Pellet Cooler Up 1500x1500x1670 0.446 windnet, meganetic separator and 24 bags of bag filter.
3 Pellet Coller Down 2150x1670x1800 1.128 1 pc of top of bin;
4 pcs of bin plate.
4 Down Frame of Vibraton Sifter 1930x1670x1360 0.794 18 pc of elevator pipes;
155 pc of buckets;
12 pc support steels of the bin.
5 1000 cyclone for pellet cooling 2400x1100x1160 0.42 1 sets of 9L air lock;
2 pc of bucket elevator belt
6 1000 Cyclone for Hammer Mill 2400x1100x1160 0.37 2 sets of 5L air lock
7 Control Cabinet 1160x810x2070 0.4 　
8 SPM520 Pellet Mill
(Including Conditioner)		 2700x2200x2200
(steel support)		 6.2 　
9 Feeder of SPM 520 Pellet Mill 1950x1400x1000 0.472 1 pc of eccentric shaft adjustment tool;
1 pc of hook wrench;
1 pc of ring die hook;
1 pc of roller lifting;
1 pc of torque wrench;
1 pc of φ30 sleeve;
1 pc of Magnetic stand, and 1 pc of dial indicator;
8 sets of φ75x2.65 seal ring;
6 pcs of  M20x80 bolts;
5 pcs of safety pin;
4 pcs of Rubber shock pad (20x200x120);
1 set of pneumatic grease pump;
1 coil pf 40x4 seal strip;
1 unit of up level indicator of the bin;
1 unit of down leverl indicator of the bin;
1 unit of leverl indicator of pellet cooler;
14 pcs of coulpers for bucket elevator.
10 Silo Cone 1520x1520x1450 0.596 1 pc of up component of bag filter;
Non-standard steel pipe changes and flange;
4 pcs of 125 hand wheels of bucket elevators;
Standard components (bolts);
50 pcs of hose clamp;
22 pcs of cushions of buckect elevator pipes;
10 sets of S1 belt fastener;
350 sets of bucket bolts;
1 pcs of level indicator base;
1 pc of wind gate;
11 30 L Air Lock 1060x1060x870 0.246 Body of magnetic separator.
12 Down part of bag filter 1210x850x2030 0.324 1 set of 9-26-5A fan
13 Frame of bag filter 1260x870x2200 0.256 1 pc of 4-72-7.5KW fan;
1 pc of crusher cyclone buffer output.
14 219 circular round pipe 6100x520x550 0.324 　
15 Hoppper 800x600x820 0.048 　
16 Support of conveyor 1650x550x230 0.034 　
17 Belt conveyor for Hammer Mill 6020x1600x1700 0.616 　
18 Hammer Mill 2500x1200x2000 1.87 　
19 Air compressor 1200x460x850 0.1 　
20 Pellet Conveyor 2200*500*200 0.11 　
21 Motor and Reducer of Pellet Conveyor 600*180*200 0.015 　
　 Total 　 15.405 　


Release date: 2017-05-04
