Here’s an example to show you how to calculate the wood sawdust dryer’s capacity:



I, Raw Material and Process Requirement:

Material: Wood sawdust

Original moisture content: 45%

Dry material moisture content: 15%

Equipment specification: triple-layer, 2.4m*12m (outside diameter)

II, Temperature of Each Stage:

Inner Stove: 350 ℃ (hot air)

Input Rotary Drum: 270~300 ℃ (hot air)

Output: 90~110 ℃ (hot air)

Output: 50~60 ℃ (material, finished product)

III Calculation Process:

1, Set x as how many kilos dry material could be produced by one ton of raw material,

and then: 1 * (1-45%) = x * (1-15%), get x=0.6471

2, Area Calculation of Rotary Drum:

① Outer Layer:

Circumference * Length → 2 * π * R * 14 → 2 * 3.14 * 1.2 * 14 = 105.504m2

② Middle Layer

Circumference * Length → 2 * π * R * (14-0.5) → 2 * 3.14 * (1.2-0.25) * 13.5 = 80.541m2

③ Inner Layer:

Circumference * Length → 2 * π * R * (14-0.5) → 2 * 3.14 * (0.95-0.25) * 13.5 = 59.346m2

Total: ① + ② + ③  = 245.391m2

3, The evaporation capacity per square meter per 24 hours: 218kg;

4, Total evaporation capacity is: 245.391 * 218kg = 53495.238kg = 53.495238 tons;

5, The evaporation water of one ton raw material: 1-0.6471t = 0.3529t;

6, Set x as quantity of raw material (tons) which could produce 53.495238 tons water, and

x*0.3529 = 53.495238, then get x = 151.5875 tons;

7, The total capacity of drying system: 151.5875 * 0.6471 = 98.09227125 tons;

8, Output capacity per hour: 98.09227125÷24h = 4.09t/h;

9, Process of raw material per hour: 151.5875 ÷24h = 6.316t/h.
